We offer you the advantage to buy everything from one hand in without having to have the risk of dependency.
Assigo offers the main groups Electro and Metal components.


Wire and cable assemblies

We offer quality wire harnesses and assemblies for products in numerous industries. From industrial equipment, Off-road, Automotive, agriculture and medical equipment, to appliances and general consumer goods, you can rely on extensive experience in creating products for most any application.
The production facilities utilize a combination of automated production with manual production to assure the fastest possible lead times while maintaining a zero-defects quality initiative. The delivery of flawless components is the goal, for every customer, every time.

Battery cables
Assigo offers custom battery cable assemblies for many applications. We are your premier contract manufacturing resource for power and high-current conductors intended for severe, rugged environments. We provide a complete range of cable sizes for  different purposes. Whether it is 4mm² or 240mm², we are your  partner.

Common Options are
Label identification - Heat shrink with adhesive - Soldering - Molded terminal caps installed - Corrugated or braided loom covering

We use automated, high-speed cutting, stripping and crimping processes whenever possible. These automated processes improve process repeatability, increasing the overall quality of our products. Of course, process control and quality assurance are applied to ensure our processes remain in control.

We offer built-to-spec products that precisely meet your needs. RoHS compliant products are available as required.

Cabinets
We offer the possibility to have your electrical cabinet, control panel or dashboard custom made. Both the cabinet as well as the wiring system inside it will be built to your specification. Next to that we will support in the development, if desired, to come to the best solution possible.

Electro technical components
The electro technical components include the whole range of (vehicle) electrics and electronics. These two groups are further divided into electronic components, camera systems, relays, fuses, cables, lights, mirrors, switches, indicators, connectors etc. – everything a wire can be connected to. And, if required, we can also make it wireless.

For a detailed products overview, please refer to the full catalogue



Turning and milling parts
Assigo has extensive possibilities in the field of turning and milling parts. Reliable, high standards and to your specification is what you can expect. The possibilities are endless. See for yourselves in this overview.

Turning

CNC-turning centers with driven tools
CNC-turning machines up to 65 mm pass through, in chuck up to Ø215 mm
Single spindel lathes electrohydraulic, curve- and CNC-controlled from 2 to 60 mm pass through
Multiple spindel lathes  up to 42 mm pass through
Long lathes conventional- und CNC-controlled up to 26 mm pass through


Milling & Drilling

Modern CNC-machining centers X = 500, Y = 380, Z = 300
Conventional Milling and Drilling Machine


Gear Milling

Hobmilling
Wormmilling
Spur toothing- and helical gearing Ø 3,5 to 145 mm, max. length 140 mm, Modul 0,2 to 2,5
Worm wheels Ø  8 to 145 mm,  Modul 0,2 to 2,5
Worms Ø 4 to 60 mm, max. length 100 mm, Modul 0,2 to 2


Grinding

Centerless infeed grinding Ø 2 to 60 mm, max. length 300 mm, automatic and manual
Through feed grinding
Grinding between centers Ø 5 to 350 mm, max. length 600 mm


Pressing, Stamping
& Special Manufacturing

Copper and brass with certified partners
Stamping, bending, imprinting and broaching for small and medium series


Surfacefinish

Strapping
Polishing manual or semi-automatic
Vibratory finishing
Tumble ploshing
Blasting


Prototypes, Samples
& Mini Series

CNC-turning machines with driven tools
CNC-machining centers with roundtables


Assembly

Assembly lines for subassemblies with function tests and inspection reports


Surface
Treatment

With Certified Partners
Galvanic e.g. zinc coating, nickel-, chrome- and gold plating
Chemical e.g. barnishing, phosphatizing
Anodic e.g. anodic oxidation and hart coat anodizing


Heat
Treatment

With Certified Partners:
Hardening e.g.carburizing, carbonizing, induction hardening
Annealing


Heads and caps

Another specialist product for which you can contact Assigo, are heads and caps. Products which are mainly thought of as being used in the petrochemical industry. If you look closely you will recognize that this is not where it ends! You will also find heads and caps in numerous applications like e.g.: trailer tanks, end caps for fence poles, fuel tanks , caps for fittings or even as a firebowl in your garden. You can choose all kinds of geometries in different materials directly from stock available (about 600 ton).
Heads you need tomorrow, our partner already pressed yesterday!!

Would your specific requirement not be available directly from stock we produce it for you. Whether  it is a standard product or it has to be custom made. Even for laser machined cut-outs are among the possibilities.

Below you will find a listing of what we have available.
Feel free to check what heads and caps are available directly from stock


Torispherical heads to DIN 28011 specifications
(r1 = da, r2 = 0,1 da)
Hot or cold formed / annealed
Diameter:
Use gauges:
21,3

until
until
1600 mm
160 mm


Deep-dished torispherical heads to DIN 28013
(r1 = 0,8 da, r2 = 0,154 da)
Hot or cold formed / annealed
Diameter:
Use gauges:

21,3

until
until
1600 mm
160 mm


Hemispherical heads
(r1 = 0,5 di)
Hot or cold formed / annealed
Diameter:
Use gauges:

21,3

until
until
1200 mm
120 mm


Normal dished heads
(r1 = da, r2 = 15 bis 50 mm)
Hot or cold formed
Diameter:
Use gauges:

300

until
until
1600 mm
160 mm


Flat heads
(r2 = 15 bis 50 mm)
Hot or cold formed
Diameter:
Use gauges:

21,3

until
until
1600 mm
160 mm


Diffuser heads
rdius of choice
possible (r1 = da, r2 = 0,1 da)
Hot or cold formed
Diameter:
Use gauges:

21,3

until
until
1600 mm
160 mm


Plate-shaped heads
(r1 = 0,8 di bis r1 = di)
Hot or cold formed
Diameter:
Use gauges:

21,3

until
until
1600 mm
160 mm


Dished Only ends
(r1 = 0,8 di bis r1 = 1600mm)
Hot or cold formed / annaeled
Diameter:
Use gauges:

21,3

until
until
1600 mm
160 mm


Caps / ANSI caps / EN (DIN) caps

Hot or cold formed / annaeled
Diameter:
Use gauges:

21,3

until
until
1600 mm
160 mm


Elliptical heads
ASME axis ratio (2:1)
NFE axis ratio (1,9:1)
Hot or cold formed / annealed
Diameter:
Use gauges:

21,3


until
until

1600 mm
160 mm


Cones with/without flared necks
Radius of choice, preferably (r = 0.1 r = 0.154 diameter or diameter)
"R" should be designed with us and drafted as far as possible to accommodate existing tools.
Warm- or cold-formed, with or without collaring on smallest diameter
Either seamlessly formed from a blank or from raw cones with seams, depending on the geometry.



Diameter:
Use gauges:

21,3


until
until

1220 mm
100 mm


Oval Hand Hole Locks
Oval Hand Hole Locks
Welding ring and hot-formed lid.
Dimensions 100/150 mm are available for all pressure levels.
Please request information on our seals!

If you have any questions, contact us, we will be happy to help!



Glass

Curved and Flat Glass

The benefits of Curvet glass
- small series or large quantities
- for all sectors and industries, from automotive to interior design
- for all kinds of projects
- the possibility of many shapes
- available in many forms, from float to laminated annealed
- silkscreen printed, coloured, customised with brands and logos

Curvet production processing of the glass
- cutting
- shaping
- bevelling
- drilling
- sandblasting
- silk-screen printing
- enamelling
- toughening
- chemical toughening
- glueing
- bending without toughening
- bending with toughening
- heat soak test
- fusion
- lamination
- double glazing

Curvet offers all types of glass to meet the various demands and applications.
- float
- extra clear - low iron
- parsol grey, bronze, green or rose-coloured
- blue
- mirrored
- laminated
- insulating glass
- low-e
- reflective
- selective
- solar control
- pyrolytic coating
- frosted
- slip resistant
- coloured enamel of lacquer
- printed
- anti-bacterial
- reinforced protective
- anti-reflective
- fire resistant
- hydro repellant

Based on our long-term experience, the comprehensive manufacturing capabilities combined with extensive processing expertise enables Curvet to offer custom-made solutions for all sectors and industries:
